WiDy SWIR products
We offer WIDy SWIR cameras from NIT. The corresponding image sensor is no more offered as a component.
The NATIVE WDR™ Sensors are based on a new generation of CMOS imaging technology named MAGIC™ (Matrice Active à Génération d’Image indexée sur Contraste), capable of generating a highly stable image even under very wide intra scene dynamic range (>120 dB) in a single frame time and without multi-exposure, any setting of knee points or external control.
WiDy SWIR camera series
WiDy SenS 320
COST-EFFECTIVE SWIR CAMERA
- QVGA 320×256 resolution @ 15µm pixel pitch
- Unique dual-response InGaAs sensor (Lin & Log)
- Up to 1kHz
- USB3.0 or CameraLink interfaces
- 30 mm cage system compatible
WiDy SenS 640
HIGH SENSITIVITY & HDR CAMERA
- The best trade-off on market
- Unique dual-response InGaAs sensor (Lin & Log)
- VGA 640×512 resolution @15 µm pixel pitch
- USB 3.0, CameraLink, GigE, Analog or SDI interface (GUI & SDK compatibility)
- TEC1
- Bad pixels replacement and smart non-uniformity correction (NUC)
- Gated mode option (Fastest gating capability)
- Available in Compact & Embedded
WiDy SenS 1280
HIGH SENSITIVITY SXGA SWIR CAMERA
- SXGA resolution – 1280x1024px @10µm pixel pitch
- Linear response mode: High sensitivity
- Read-out noise 30e-
- USB 3.0 or CameraLink interface
- TEC1
- Bad pixels replacement and non-uniformity correction (NUC)
HiPe SenS 640
HIGH-PERFORMANCE AIR-COOLED SWIR CAMERA
- Low Dark current for Long exposure applications
- VGA resolution – 640x512px @15µm pixel pitch
- USB 3.0 or CameraLink interface
- TEC2 & Fan Air-cooled
- Bad pixels replacement and non-uniformity correction (NUC)
WiDy SWIR 320
QVGA HDR SWIR CAMERA
- QVGA 320×256 HDR SWIR camera, 25 µm pixel pitch
- TECless, low-power consumption with NIT patented HDR technology (120dB)
- USB3.0 or CameraLink interface
- Compact and low power consumption camera
- Cost-effective solution
WiDy SWIR 640
VGA HDR SWIR CAMERA
- VGA 640×512 SWIR camera with patented HDR technology (120dB) @ 15µm pixel pitch
- USB 3.0, CameraLink, GigE, or Analog interface (GUI & SDK compatibility)
- TECless
- Available in compact & embedded
WiDy Nano 640
ULTRA-COMPACT MINIATURE SWIR MODULE
- VGA 640×512 @ 15 µm pixel pitch
- Plug-and-play
- Small form factor for embedded platforms
- High Dynamic Range 120 dB
- Low power consumption
- TECless
- Up to 100 fps full frame
- USB3.0
LiSa SWIR 2048
LINE-SCAN ARRAY SWIR CAMERA
- Line-scan 2048×1 SWIR camera @ 7.5 µm pixel pitch
- Linear response mode: high sensitivity
- CameraLink interface
- Bad pixels replacement and embedded non-uniformity correction (NUC)
